How to use Let's Encrypt with an SSH Bastion

by Russell Jones

This blog post is about configuring the Teleport SSH proxy (aka, bastion) to use x509 certificates (AKA SSL or HTTPS) issued by Let's Encrypt. Let's be careful and not confuse x509 certificates with SSH certificates. Teleport itself is a clustered, certificate-based SSH server (i.e., the Teleport Auth Service acts as an SSH certificate authority (CA) for your organization.)

lets encrypt bastions
lets encrypt bastions

A Teleport user must request an SSH certificate before connecting to any Teleport nodes. Typically, the certificate automatically expires at the end of the day, so the process of issuing a user SSH certificate happens daily. A user can request their SSH certificate from a Teleport proxy server:

$ tsh login

The Teleport proxy server behind uses the HTTPS protocol (on port 3080 by default) to serve the SSH certificate back to the tsh client. This means that a Teleport proxy must use a valid x509 certificate to securely serve via HTTPS. Below, we'll go through the steps for using Let's Encrypt to provide this x509 certificate.

Let's Encrypt

From the Let's Encrypt website:

Let’s Encrypt is a free, automated, and open certificate authority (CA), run for the public’s benefit. It is a service provided by the Internet Security Research Group (ISRG).

In this post we won't go into a lot of detail about how Let's Encrypt works but the most important highlights are:

  • The process of validating a certificate domain is automated.
  • A certificate issued by Let’s Encrypt is valid for just a couple of weeks and must be renewed frequently.

We'll use domain validation based on HTTP ACME challenge, which works by "provisioning an HTTP resource under a well-known URI", in our case it's This means the port 80 on the Teleport Proxy server machine must be available and accessible by Let's Encrypt servers.

Initial Setup

First, you need to install CertBot, the official Let's Encrypt client, which is a command line utility we’ll use below to receive a x509 certificate for domain. Using Debian 9, it's as simple as typing:

$ sudo apt-get install certbot

You can follow one of the official tutorials on how to obtain a certificate from Let's Encrypt but here’s how we recommend doing it:

sudo certbot certonly --standalone \
                      -d \
                      -n \
                      --agree-tos \
                      [email protected]

Here is some more detail:

--standaloneUse standalone domain validation. This will cause certbot to launch a web server listening on port 80 to respond to a ACME challenge. This is also why we have to run this command under sudo, otherwise certbot will not be able to bind to this port
-dDomain we're requesting a certificate for. This must be the same name which will be used with tsh login
-nRun non-interactively
--agree-tosTells Let's Encrypt that you agree with their Terms of Service.
--emailYour email address

By default, this command will create /etc/letsencrypt/ directory and populate it with all kinds of interesting information. We are mostly interested in /etc/letsencrypt/live/

$ ls -lh /etc/letsencrypt/live/
lrwxrwx--- 1 root root  43 Jan 18 14:28 cert.pem
lrwxrwx--- 1 root root  44 Jan 18 14:28 chain.pem
lrwxrwx--- 1 root root  48 Jan 18 14:28 fullchain.pem
lrwxrwx--- 1 root root  46 Jan 18 14:28 privkey.pem
-rw-r--r-- 1 root root 543 Jan 18 14:22 README

We'll need the private key and the "full chain" certificate to configure the Teleport Proxy.

Teleport Configuration

Open /etc/teleport.yaml and make sure it contains the following section:

  enabled: yes
  https_cert_file: /etc/letsencrypt/live/
  https_key_file: /etc/letsencrypt/live/

Restart the Teleport proxy and it should be able to serve a valid HTTPS content running on

Certificate Renewals

As we mentioned earlier, a certificate issued by Let's Encrypt is valid only for a few weeks, which means it must be renewed periodically. You can run this command periodically (see letsencrypt rate limit guidelines) as root:

$ certbot certonly --standalone -d -n --force-renewal

As you can see, it forces the renewal of the certificate. The Teleport proxy must be restarted after it runs. Another option is to run it more frequently but you will have to drop --force-renewal flag. CertBot is smart enough not to touch a certificate if it's still valid.

You can configure this command to run as a cron job or you can use systemd timers. The Certbot package from Debian 9, which we used for this post, comes with the pre-configured systemd timer which you can configure by editing these two files:


Teleport cybersecurity blog posts and tech news

Every other week we'll send a newsletter with the latest cybersecurity news and Teleport updates.


To recap, here's what we have done to configure an SSH Bastion to serve HTTPS content using a certificate from Let's Encrypt:

  1. Install certbot on the same server where a Teleport proxy is running.
  2. Make sure the port 80 is available and accessible by Let’s Encrypt servers.
  3. Use "standalone" domain verification method.
  4. Update Teleport configuration in /etc/teleport.yaml
  5. Create a systemd timer which renews the certificate and restarts Teleport daemon.
